Logging

Context Logging

Since pypz has a multi-layered design and entities on each layer are existing in their own context, we want to have a logging concept that is consistent and reusable across contexts. For example, if a plugin wants to log something, then it would be nice to reuse the logger of the operator, but denoting that the log came from the plugin’s context.

operator.get_logger().info("something")
plugin.get_logger().info("something")

INFO | pipeline | operator - something
INFO | pipeline | operator | plugin - something

Note

Since a pipeline is a virtual organization of operators, it does not have logger interface, but acts as a context for the operators.

So we have the following requirements:

• one logger to rule them all

• context information shall be available based on from where the logger is called

The concept involves the following classes:

• ContextLoggerInterface

• ContextLogger

The ContextLoggerInterface shall be used to implement the actual logging functionality. Notice that this class provides protected methods that shall not be called directly. The ContextLogger provides the functionality to call the methods of ContextLoggerInterface so that it supplies the context information in the background. You will then use a ContextLogger object to perform logging.

Operator Logging

Since an operator is a self-contained entity, we need to ensure that there is only one logger within an operator context, which can be used by the operator and the nested plugins as well. An additional twist to the story that there might be multiple logger plugins in an operator. Instead of calling each logger plugins’ corresponding methods manually, we want to abstract this, so for the user it seems to be a single method call.

The following diagram shows the inheritance map of the logging-relevant classes:

Inheritance diagram

Notice that the LoggerPlugin interface inherits from the ContextLoggerInterface, so if you implement a logger plugin, then you actually implement the ContextLoggerInterface.

Furthermore, there is a ContextLoggerInterface implementation in the Operator: pypz.core.specs.operator.Operator.Logger.

This class implements the functionality to abstract the method call of all LoggerPlugins in the operator context.

If you check the Operator’s constructor, you will notice the member self.__logger. This is actually a ContextLogger object, where the Operator.Logger is provided as logger implementation and the context is the full name of the operator. This is the one and only logger in the entire operator context. If a plugin is created within this context, then it creates its own ContextLogger object, however as the logger implementation it will take the logger of the operator, while adding its own context to the context list. Hence, if any logger method will be called inside the plugin, it will be routed to the operator’s ContextLogger, which invokes the implemented method of the Operator.Logger, which will call all the LoggerPlugins’ corresponding method.

To access the logger in either the operator or plugin context, you simply need to invoke the get_logger() method.

operator.get_logger().info("something")
plugin.get_logger().info("something")

Warning

Currently there is a guard in Operator.Logger, which will trace back the call stack and will throw an exception if a LoggerPlugin tries to invoke any of the logger methods. This will prevent recursion at a cost of some CPU load.
